Borewell Piping System

Your TRU companion for water sourcing

Screen Pipes

1 1/2” to 16” (40mm to 400mm)

Casing Pipes

1 1/2” to 12” (40mm to 305mm)

Column Pipes

1” to 4” (25mm to 100mm)

Certified By

IS:12818

Applications

Agriculture

Residentials

Commercial

Key Advantages

Product Details

Medium Well Screen (Rms) & Deep Well Screen (Rds) Pipes With Ribs/ribbed Screen Pipes

				Medium Well Screen (RMS)			Deep Well Screen (RDS)
Nominal Diameter (DN)		Mean Outer Diameter of pipe (d) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness (e) (under ribs) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness, e’ (mm)
mm	inches	Min	Max	Max	Min	Max	Max	Min	Max
40.0	1 1/2	52.00	52.20	56.00	3.50	4.00	—	—	—
50.0	2	64.00	64.20	69.00	4.00	4.60	—	—	—
80.0	3	92.00	92.30	98.00	4.00	4.60	—	—	—
100.0	4	117.00	117.30	124.00	5.00	5.70	129.00	7.00	7.90
115.0	4 1/2	129.00	129.30	—	—	—	141.00	7.50	8.50
125.0	5	144.00	144.40	154.00	6.50	7.30	156.00	8.00	9.00
150.0	6	169.00	169.40	182.00	7.50	8.50	184.00	9.50	10.70
175.0	7	204.00	204.50	219.00	8.80	9.80	221.00	11.80	13.60
200.0	8	229.00	229.50	247.00	10.00	11.20	251.00	13.00	14.80
250.0	10	284.00	284.50	302.00	12.50	14.00	309.00	16.00	17.60
300.0	12	334.00	334.60	356.00	14.50	16.20	363.00	19.00	21.00
350.0	14	404.00	404.70	432.00	17.50	19.50	437.00	21.50	23.90
400.0	16	454.00	454.80	483.00	19.50	21.70	494.00	23.50	26.10

Plain Medium Well Screen (Pms) & Plain Deep Well Screen (Pds) Pipes

				Plain Medium Well Screen (PMS)			Plain Deep Well Screen (PDS)
Nominal Diameter (DN)		Mean Outer Diameter of pipe (d) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness (e) (mm)		Outer Diameter at any point d’e’ (mm)		Mean Outer Diameter over Connection, d’x’	Wall Thickness, e’ (mm)
mm	inches	Min	Max	Max	Min	Max	Min	Max	Max	Min	Max
200.0	8	225.00	225.50	243.00	10.00	11.20	224.50	225.80	247.00	13.00	14.80
250.0	10	280.00	280.50	298.00	12.50	14.00	279.40	280.80	304.00	16.00	17.60
300.0	12	330.00	330.60	352.00	14.50	16.20	329.30	331.00	359.00	19.00	21.00
350.0	14	400.00	400.70	428.00	17.50	19.50	399.20	401.20	433.00	21.50	23.90
400.0	16	450.00	450.80	479.00	19.50	21.70	449.10	451.30	490.00	23.50	26.10

Medium Well Casing (Cm) & Shallow Well Casing (Cs) Pipes

				Medium Well Casing (CM) Pipes			Shallow Well Casing (CS) Pipes
Nominal Diameter (DN)		Mean Outer Diameter of pipe (d) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness e (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness, e’ (mm)
mm	inches	Min	Max	Max	Min	Max	Max	Min	Max
40.0	1 1/2	48.00	48.20	52.00	3.50	4.00	—	—	—
50.0	2	60.00	60.20	65.00	4.00	4.60	—	—	—
80.0	3	88.00	88.30	94.00	4.00	4.60	—	—	—
100.0	4	113.00	113.30	120.00	5.00	5.70	—	—	—
125.0	5	140.00	140.40	150.00	6.50	7.30	—	—	—
150.0	6	165.00	165.40	178.00	7.50	8.50	174.00	5.70	6.50
175.0	7	200.00	200.50	215.00	8.80	9.80	211.00	7.00	7.80
200.0	8	225.00	225.50	243.00	10.00	11.20	238.00	7.60	8.80
250.0	10	280.00	280.50	298.00	12.50	14.00	292.00	9.60	11.00
300.0	12	330.00	330.60	352.00	14.50	16.20	—	—	—

Deep Well Casing (Cd) Pipes

Nominal Diameter (DN)			Mean Outer Diameter of pipe d’e’m’ (mm)		Outer Diameter at any point d’e’ (mm)		Mean outer Diameter over Connection, (d’x’)	Wall thickness, ‘e’ (mm)
mm	inches	Min	Max	Min	Max	Max	Min	Max
100.0	4	113.00	113.30	112.80	113.40	125.00	7.00	7.90
115.0	4 1/2	125.00	125.30	124.90	125.40	137.00	7.50	8.50
125.0	5	140.00	140.40	139.70	140.50	152.00	8.00	9.00
150.0	6	165.00	165.40	164.60	165.60	180.00	9.50	10.70
175.0	7	200.00	200.50	199.60	200.60	217.00	11.80	13.60
200.0	8	225.00	225.50	224.50	225.80	247.00	13.00	14.80
250.0	10	280.00	280.50	279.40	280.80	304.00	16.00	17.60
300.0	12	330.00	330.60	329.30	331.00	359.00	19.00	21.00
350.0	14	400.00	400.70	399.20	401.20	433.00	21.50	23.90
400.0	16	450.00	450.80	449.10	451.30	490.00	23.50	26.10

Submersible Delivery Pipes/rising Main Pipes/column Pipes

Product OD-Outside Dia. ND-Nominal Dia. In mm			Pressure Kg/cm²	Safe total pump delivery Head (m)	Ultimate Breaking Load (Kg)	Safe Pulling Load (Kg)	Screen Colour	STD Packing
Size	Type	Category
1″ OD-33.30 ND-25.00	Coupler	V 4	12.5	125	850	500	Royal Claret	28
		V 4	17	170	950	600	Green	28
		Medium	22	220	1250	750	Orange	28
		Std	38	380	1750	1100	Red	28
	Bell Form Coupler	V 4	12.5	125	850	500	Royal Claret	28
	Bell Form Coupler	V 4	17	170	950	600	Green	28
1 1/4″ OD-42.10 ND-32.00	Coupler	V 4	12.5	125	1350	800	Royal Claret	20
		V 4	17	170	1500	900	Green	20
		Medium	21	210	1725	1000	Orange	20
		Std	30	300	2350	1400	Red	20
		Heavy	39	390	2900	1750	Blue	20
	Bell Form Coupler	V 4	12.5	125	1350	800	Royal Claret	20
	Bell Form Coupler	V 4	17	170	1500	900	Green	20
1 1/2″ OD-48.20 ND-40.00	Coupler	V 4	16	160	1850	1100	Green	16
		Medium	22	220	2400	1450	Orange	16
		Std	26	260	2750	1650	Red	16
		Heavy	39	390	3700	2250	Blue	16
2″ OD-60.20 ND-50.00	Coupler	Medium	14	140	2450	1450	Orange	12
		Std	20	200	3500	2100	Red	12
		Heavy	27	270	4600	2800	Blue	12
2 1/2″ OD-75.00 ND-65.00	Coupler	Medium	11	110	3100	1800	Orange	8
		Std	16	160	4500	2700	Red	8
		Heavy	26	260	6450	3900	Blue	8
3″ OD-88.00 ND-80.00	Coupler	Medium	11	110	4100	2450	Orange	6
		Std	17	170	6400	3800	Red	6
		Heavy	26	260	8900	5300	Blue	6
4″ OD-113.00 ND-100.00	Coupler	Medium	10	100	6500	3900	Orange	4
		Std	15	150	9250	5550	Red	4
		Heavy	26	260	14450	8700	Blue	4

Note: Submersible pipes with ‘Bellform’ available on 1” & 11/4” – v4 catergory with 12.5 & 17kg pressure ratings

No details yet!

Product Details

Pipe Dimensions

Medium Well Screen (Rms) & Deep Well Screen (Rds) Pipes With Ribs/ribbed Screen Pipes

				Medium Well Screen (RMS)			Deep Well Screen (RDS)
Nominal Diameter (DN)		Mean Outer Diameter of pipe (d) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness (e) (under ribs) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness, e’ (mm)
mm	inches	Min	Max	Max	Min	Max	Max	Min	Max
40.0	1 1/2	52.00	52.20	56.00	3.50	4.00	—	—	—
50.0	2	64.00	64.20	69.00	4.00	4.60	—	—	—
80.0	3	92.00	92.30	98.00	4.00	4.60	—	—	—
100.0	4	117.00	117.30	124.00	5.00	5.70	129.00	7.00	7.90
115.0	4 1/2	129.00	129.30	—	—	—	141.00	7.50	8.50
125.0	5	144.00	144.40	154.00	6.50	7.30	156.00	8.00	9.00
150.0	6	169.00	169.40	182.00	7.50	8.50	184.00	9.50	10.70
175.0	7	204.00	204.50	219.00	8.80	9.80	221.00	11.80	13.60
200.0	8	229.00	229.50	247.00	10.00	11.20	251.00	13.00	14.80
250.0	10	284.00	284.50	302.00	12.50	14.00	309.00	16.00	17.60
300.0	12	334.00	334.60	356.00	14.50	16.20	363.00	19.00	21.00
350.0	14	404.00	404.70	432.00	17.50	19.50	437.00	21.50	23.90
400.0	16	454.00	454.80	483.00	19.50	21.70	494.00	23.50	26.10

Plain Medium Well Screen (Pms) & Plain Deep Well Screen (Pds) Pipes

				Plain Medium Well Screen (PMS)			Plain Deep Well Screen (PDS)
Nominal Diameter (DN)		Mean Outer Diameter of pipe (d) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness (e) (mm)		Outer Diameter at any point d’e’ (mm)		Mean Outer Diameter over Connection, d’x’	Wall Thickness, e’ (mm)
mm	inches	Min	Max	Max	Min	Max	Min	Max	Max	Min	Max
200.0	8	225.00	225.50	243.00	10.00	11.20	224.50	225.80	247.00	13.00	14.80
250.0	10	280.00	280.50	298.00	12.50	14.00	279.40	280.80	304.00	16.00	17.60
300.0	12	330.00	330.60	352.00	14.50	16.20	329.30	331.00	359.00	19.00	21.00
350.0	14	400.00	400.70	428.00	17.50	19.50	399.20	401.20	433.00	21.50	23.90
400.0	16	450.00	450.80	479.00	19.50	21.70	449.10	451.30	490.00	23.50	26.10

Medium Well Casing (Cm) & Shallow Well Casing (Cs) Pipes

				Medium Well Casing (CM) Pipes			Shallow Well Casing (CS) Pipes
Nominal Diameter (DN)		Mean Outer Diameter of pipe (d) (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness e (mm)		Mean Outer Diameter over Connection, (d’x)	Wall Thickness, e’ (mm)
mm	inches	Min	Max	Max	Min	Max	Max	Min	Max
40.0	1 1/2	48.00	48.20	52.00	3.50	4.00	—	—	—
50.0	2	60.00	60.20	65.00	4.00	4.60	—	—	—
80.0	3	88.00	88.30	94.00	4.00	4.60	—	—	—
100.0	4	113.00	113.30	120.00	5.00	5.70	—	—	—
125.0	5	140.00	140.40	150.00	6.50	7.30	—	—	—
150.0	6	165.00	165.40	178.00	7.50	8.50	174.00	5.70	6.50
175.0	7	200.00	200.50	215.00	8.80	9.80	211.00	7.00	7.80
200.0	8	225.00	225.50	243.00	10.00	11.20	238.00	7.60	8.80
250.0	10	280.00	280.50	298.00	12.50	14.00	292.00	9.60	11.00
300.0	12	330.00	330.60	352.00	14.50	16.20	—	—	—

Deep Well Casing (Cd) Pipes

Nominal Diameter (DN)			Mean Outer Diameter of pipe d’e’m’ (mm)		Outer Diameter at any point d’e’ (mm)		Mean outer Diameter over Connection, (d’x’)	Wall thickness, ‘e’ (mm)
mm	inches	Min	Max	Min	Max	Max	Min	Max
100.0	4	113.00	113.30	112.80	113.40	125.00	7.00	7.90
115.0	4 1/2	125.00	125.30	124.90	125.40	137.00	7.50	8.50
125.0	5	140.00	140.40	139.70	140.50	152.00	8.00	9.00
150.0	6	165.00	165.40	164.60	165.60	180.00	9.50	10.70
175.0	7	200.00	200.50	199.60	200.60	217.00	11.80	13.60
200.0	8	225.00	225.50	224.50	225.80	247.00	13.00	14.80
250.0	10	280.00	280.50	279.40	280.80	304.00	16.00	17.60
300.0	12	330.00	330.60	329.30	331.00	359.00	19.00	21.00
350.0	14	400.00	400.70	399.20	401.20	433.00	21.50	23.90
400.0	16	450.00	450.80	449.10	451.30	490.00	23.50	26.10

Submersible Delivery Pipes/rising Main Pipes/column Pipes

Product OD-Outside Dia. ND-Nominal Dia. In mm			Pressure Kg/cm²	Safe total pump delivery Head (m)	Ultimate Breaking Load (Kg)	Safe Pulling Load (Kg)	Screen Colour	STD Packing
Size	Type	Category
1″ OD-33.30 ND-25.00	Coupler	V 4	12.5	125	850	500	Royal Claret	28
		V 4	17	170	950	600	Green	28
		Medium	22	220	1250	750	Orange	28
		Std	38	380	1750	1100	Red	28
	Bell Form Coupler	V 4	12.5	125	850	500	Royal Claret	28
	Bell Form Coupler	V 4	17	170	950	600	Green	28
1 1/4″ OD-42.10 ND-32.00	Coupler	V 4	12.5	125	1350	800	Royal Claret	20
		V 4	17	170	1500	900	Green	20
		Medium	21	210	1725	1000	Orange	20
		Std	30	300	2350	1400	Red	20
		Heavy	39	390	2900	1750	Blue	20
	Bell Form Coupler	V 4	12.5	125	1350	800	Royal Claret	20
	Bell Form Coupler	V 4	17	170	1500	900	Green	20
1 1/2″ OD-48.20 ND-40.00	Coupler	V 4	16	160	1850	1100	Green	16
		Medium	22	220	2400	1450	Orange	16
		Std	26	260	2750	1650	Red	16
		Heavy	39	390	3700	2250	Blue	16
2″ OD-60.20 ND-50.00	Coupler	Medium	14	140	2450	1450	Orange	12
		Std	20	200	3500	2100	Red	12
		Heavy	27	270	4600	2800	Blue	12
2 1/2″ OD-75.00 ND-65.00	Coupler	Medium	11	110	3100	1800	Orange	8
		Std	16	160	4500	2700	Red	8
		Heavy	26	260	6450	3900	Blue	8
3″ OD-88.00 ND-80.00	Coupler	Medium	11	110	4100	2450	Orange	6
		Std	17	170	6400	3800	Red	6
		Heavy	26	260	8900	5300	Blue	6
4″ OD-113.00 ND-100.00	Coupler	Medium	10	100	6500	3900	Orange	4
		Std	15	150	9250	5550	Red	4
		Heavy	26	260	14450	8700	Blue	4

Note: Submersible pipes with ‘Bellform’ available on 1” & 11/4” – v4 catergory with 12.5 & 17kg pressure ratings

Fittings

Properties

No details yet!

Installation Guide

Follow these guidelines to install Trubore borewell piping systems effectively.

Screen & Casing Pipe

Drill the Bore

Drill a vertical bore of the required size and depth using auger, water jet, hydraulic rotary, or core drilling. Ensure the bore is straight to save on labour and installation cost.

Use Casing & Screening Pipes

Casing/screen pipes are necessary for tube well construction and highly recommended in areas with loose soil, silt, or boulders for added stability.

Install Gaskets

Fix a “C” clamp below the bell end and lower the pipe using a chain pulley block. Attach a sand trap with an end plug if required.

Lower Pipe Assembly

Fix a “C” clamp below the bell end and lower the pipe using a chain pulley block. Attach a sand trap with an end plug if required.

Joint Pipes Securely

After lowering, fit a rubber gasket on the next pipe and tighten gently using a pipe or chain wrench. Avoid overtightening.

Complete Installation

Repeat the process till the required depth is achieved. Use centering guides as needed and fill gravel between the pipe and borehole.

Rising Main Pipe

Pre-check the Pump

Ensure the submersible pump is functioning properly before installation. This helps avoid delays or rework after the assembly is lowered into the borewell.

Install Metal Adapter

Securely connect the Trubore metal adaptor to the pump using a chain wrench. A firm and leak-proof joint is critical for long-term performance and durability.

Prepare for Assembly

Clean pipe threads with water to ensure smooth jointing and avoid thread damage. Also, confirm the pump guard is correctly placed between the pipe coupler and metal adaptor.

Join Delivery Pipe

Connect the submersible delivery pipe to the pump using a strap wrench or rope for final tightening. Proper tightening prevents slippage during operation and ensures a stable connection.

Add Safety Rope

Attach a nylon rope to the cast iron adaptor, run it along the bore length, and tie it at the top clamp. This acts as a safety backup to prevent the pump from falling in case of mishaps.

Lower the Assembly

Fix a “C” clamp at the marked point below the coupler and slowly lower the pipe using a chain pulley. Once at clamp level, install the rubber ring on the next pipe and gently tighten using rope before continuing.

Download Full Installation Manual
