Trubore Flowguard Plus CPVC^® Plumbing Systems

Your TRU shield against heat and corrosion

Pipes

15 to 50mm-SDR 11 & 13.5 as per IS:15778
65 to 250mm-Sch 40 & 80 as per ASTM F 441

Fittings

15 to 50mm- SDR 11 as per ASTM D 2846
65 to 100mm- Sch 80 as per ASTMF439
150mm- Sch 40 as per ASTM F438

Flange

As per ASTM-D4024 and ASME B 16.5

Applications

Mall

Hotel

Residential

Hospital

Commercial

Key Advantages

Product Details

PIPE DIMENSIONS

Nominal Bore		Outside Diameter		SDR 11				SDR 13.5
		Outside Diameter		Wall thickness		Working Pressure		Wall thickness		Working Pressure
		Min	Max	Min	Max	At 27℃	At 82℃	Min	Max	At 27℃	At 82℃
(mm)	(inch)	(mm)	(mm)	(mm)	(mm)	Kg/cm²	Kg/cm²	(mm)	(mm)	Kg/cm²	Kg/cm²
15	1/2	15.80	16	1.70	2.20	28.14	6.93	1.40	1.90	22.22	5.60
20	3/4	22.10	23.30	2.00	2.50	28.14	6.93	1.70	2.20	22.22	5.60
25	1	28.50	28.70	2.60	3.10	28.14	6.93	2.10	2.60	22.22	5.60
32	1 1/4	34.80	35.00	3.20	3.70	28.14	6.93	2.60	3.10	22.22	5.60
40	1 1/2	41.20	41.40	3.80	4.30	28.14	6.93	3.10	3.60	22.22	5.60
50	2	53.90	54.10	4.90	5.50	28.14	6.93	4.00	4.60	22.22	5.60
				Schedule 40				Schedule 80
(mm)	(inch)	(mm)		Min	Max	At 23℃	At 82℃	Min	Max	At 23℃	At 82℃
65	2 1/2	73.00(+/-0.18)		5.16	5.77	21.10	5.30	7.01	7.85	29.57	7.43
80	3	88.90(+/-0.20)		5.49	6.15	18.25	4.58	7.62	8.53	26.00	6.32
100	4	114.30(+/-0.23)		6.02	6.73	15.49	3.87	8.56	9.58	22.53	5.60
150	6	168.30(+/-0.28)		7.11	7.79	12.64	3.16	10.97	12.29	19.68	4.89
200	8	219.10(+/-0.38)		8.18	9.17	11.21	2.85	12.70	14.22	17.54	4.18
250	10	273.10(+/-0.28)		9.27	10.39	9.89	2.44	15.06	16.86	16.21	3.81

NOTE:

Dimensions with ‘*’ are not a function of SDR.
Fittings are suitable for corresponding pipe pressure rating.

TRUBORE FLOWGUARD® PLUS CPVC FITTING RANGE

Size(inch)	Standard Packaging	Small Standard Packaging
2 ^1/2	12
4	16

CONCEALED VALVE

Size(inch)	Standard Packaging	Small Standard Packaging
3/4″	1	–
1″	1	–

BALL VALVE

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	60	–
3/4	24	–
1	24	–
1 1/4	9	–
1 1/2	6	–
2	6	–

COUPLER

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	1000	200
3/4	700	100
1	425	70
1 1/4	200	40
1 1/2	150	30
2	75	15
6		–
3	48	–
4	12	–
6	8	–

CROSS OVER

Size(inch)	Standard Packaging	Small Standard Packaging
1/2″	80	–
3/4″	100	–
1″	70	–

CROSS OVER MOULDED

Size(inch)	Standard Packaging	Small Standard Packaging
3/4	100	–
1	60	–

ELBOW

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	750	120
3/4	550	80
1	275	45
1 1/4	150	20
1 1/2	100	16
2	50	10
6

Elbow 45°

Size(inch)	Standard Packaging	Small Standard Packaging
1/2″	1000	200
3/4″	400	80
1″	250	50
1 1/4″	175	–
1 1/2″	100	–
2	60	–

END CAP

Size(inch)	Standard Packaging	Small Standard Packaging
1/2″	1100	220
3/4″	900	180
1″	500	100
1 1/4″	300	60
1 1/2″	200	40
2	150	30
6

EQUAL TEE

Size(inch)	Standard Packaging	Small Standard Packaging
1/2″	500	100
3/4″	325	50
1″	225	35
1 1/4″	90	15
1 1/2″	60	12
2	35	7
6

FABRICATED BEND

Size(inch)	Standard Packaging	Small Standard Packaging
1/2″	400	–
3/4″	250	–
1″	100	–
1 1/4″	70	–
1 1/2″	50	–
2	36	–

FOUR WAY TEE

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	500	100
3/4	225	45

F.T.A

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	800	160
3/4	700	140
1	400	80
1 1/4	200	40
1 1/2	150	30
2	80	16

Open Flange

Size(inch)	Standard Packaging	Small Standard Packaging
1	60	8
1 ¼	42	6
1 ½	30	5
2	22	4
2 ½	20	–
3	13	–
4	7	–

REDUCER

Size(inch)	Standard Packaging	Small Standard Packaging
3/4 X 1/2	550	110
1 X 1/2	450	90
1 X 3/4	400	80
1 1/4 X 1/2	250	50
1 1/4 X 3/4	250	50
1 1/4 X 1	250	50
1 1/2 X 1/2	200	40
1 1/2 X 3/4	200	40
1 1/2 X 1	200	40
1 1/2 X 1 1/4	150	30
2 X 1/2	150	30
2 X 3/4	150	30
2 X 1	150	30
2 X 1 1/4	140	28
2 X 1 1/2	100	20

REDUCING BUSH

Size(inch)	Standard Packaging	Small Standard Packaging
3/4 X 1/2	1000	200
1 X 1/2	700	140
1 X 3/4	800	160
1 1/4 X 1/2	450	90
1 1/4 X 3/4	475	95
1 1/4 X 1	500	100
1 1/2 X 1/2	250	50
1 1/2 X 3/4	280	56
1 1/2 X 1	300	60
1 1/2 X 1 1/4	400	80
2 X 1/2	190	38
2 X 3/4	200	40
2 X 1	225	45
2 X 1 1/4	200	40
2 X 1 1/2	200	40

REDUCING ELBOW

Size(inch)	Standard Packaging	Small Standard Packaging
3/4 X 1/2	400	80
1 X 3/4	200	40

REDUCING MALE THREADED ADAPTOR (MTA)

Size(inch)	Standard Packaging	Small Standard Packaging
3/4 X 1/2	625	125

REDUCING TEE

Size(inch)	Standard Packaging	Small Standard Packaging
3/4 X 1/2	300	60
1 X 1/2	200	40
1 X 3/4	250	40
1 1/4 X 1/2	100	20
1 1/4 X 3/4	100	20
1 1/4 X 1	100	20
1 1/2 X 1/2	80	16
1 1/2 X 3/4	75	15
1 1/2 X 1	75	15
1 1/2 X 1 1/4	60	12
2 X 1/2	50	10
2 X 3/4	50	10
2 X 1	50	10
2 X 1 1/4	30	8
2 X 1 1/2	25	8

TANK CONNECTOR

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	150	–
3/4	200	–
1	115	–
1 1/4	60	–
1 1/2	50	–
2	30	–

Tank Connector(Plain)

Size(inch)	Standard Packaging	Small Standard Packaging
3/4″	150	30
1″	100	20

TRANSITION BUSH

Size(inch)	Standard Packaging	Small Standard Packaging
1/2 X 1/2	1000	200
3/4 X 3/4	750	150

UNION

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	250	50
3/4	250	50
1	150	30
1 1/4	75	15
1 1/2	40	8
2	30	8

FEMALE THREADED TEE

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	200	50
3/4 X 1/2	100	20
3/4	90	30
1 X 3/4	120	30
1 X 1/2	70	10
1	48	–
1 1/4	60	12

FEMALE THREADED ADAPTOR (Brass)

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	250	50
3/4 X 1/2	200	60
3/4	150	60
1 X 3/4	125	25
1 X 1/2	150	30
1	75	30
1 1/4	50	15
1 1/2	35	9
2	15	5

MALE THREADED ADAPTOR

Size(inch)	Standard Packaging	Small Standard Packaging
1/2″	1200	240
3/4″	900	180
1″	450	90
1 1/4″	250	50
1 1/2″	200	40
2	100	20

MALE THREADED ADAPTOR (HEAVY)

Size(inch)	Standard Packaging	Small Standard Packaging
1/2″	200	40
3/4″ X 1/2″	200	50
3/4″	170	34
1″	80	17
1 1/4″	40	7
1 1/2″	25	5
2″	15	3

F.T.A(HEAVY)

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	200	40
3/4	150	30
1	60	14
1 1/4	35	8
1 1/2	25	6
2	20	4

POWDERED COATED METAL CLAMP

Size(inch)	Standard Packaging	Small Standard Packaging
1/2	500	–
3/4	500	–
1	500	–
1 1/4	350	–
1 1/2	300	–
2	250	–

TIN

Size(ml)	Standard Packing (nos)	Small Standard Packing (nos)
118 ml	24	–
237 ml	24	–
473 ml	–	–
946 ml	–	–

TUBE

Size(ml)	Standard Packing (nos)	Small Standard Packing (nos)
29.5 ml	1	–
59 ml	1	–

No details yet!
