uPVC Pipe
uPVC

uPVC Plumbing Systems

Your TRU choice for clean water

Pipes

Schedule 40,80 –
As per ASTM D – 1785(Plain Ended)

Fittings

Schedule 80 as per ASTM D – 2467 Schedule 40 as per ASTM D – 2466

Applications

Commercial
Commercial
Residentials
Residentials
Industry
Industry

Key Advantages

Safe_for_drinking_water_white_transparent

Lead-free material ensures safe drinking water

ChatGPT Image Apr 1, 2025, 05_42_44 PM

Exceptional corrosion resistance ensures constant flow over its lifetime

Ruler with Heat Icon or Contracting:Expanding Arrows_white_transparent

High impact resistance. Ensures high quality performance at lower temperatures

ChatGPT Image Apr 1, 2025, 04_22_06 PM

Corrosion resistance – uPVC is rustproof material therefore, bore diamater remains constant, ensuring constant flow over its lifetime

Repair_Icon_White_Transparent

Fast and easy installation

ChatGPT Image Apr 1, 2025, 04_18_07 PM

Lightweight but strong

Shield with Water Droplets or Rust-Free Metal_white_transparent

Self-extinguishing (Does not support combustion)

Product Details

PIPE DIMENSIONS

Pressure for pipes (Solvent Weld) at 23℃
Scheduled 40 Scheduled 80
Nominal Bore Outside Diameter Wall thickness Working Pressure Wall thickness Working Pressure
(mm) (inch) (mm) (mm) Kg/cm2 (mm) Kg/cm2
15 1/2 21.34 ±0.10 2.77 + 0.51 42.20 3.73 + 0.51 59.75
20 3/4 26.67 ±0.10 2.87 + 0.51 33.75 3.91 + 0.51 48.50
25 1 33.40 ±0.13 3.38 + 0.51 31.60 4.55 + 0.53 44.25
32 1 1/4 42.16 ±0.13 3.56 + 0.51 26.00 4.85 + 0.58 36.60
40 1 1/2 48.26 ±0.15 3.68 + 0.51 23.25 5.08 + 0.61 33.00
50 2 60.32 ±0.15 3.91 + 0.51 19.65 5.54 + 0.66 28.10
65 2 1/2 73.02 ±0.18 5.16 + 0.61 21.10 7.01 + 0.84 29.55
80 3 88.90 ±0.20 5.49 + 0.66 18.25 7.62 + 0.91 26.00
100 4 114.30 ±0.23 6.02 + 0.71 15.50 8.56 + 1.02 22.50
150 6 168.28 ±0.28 7.11 + 0.86 12.60 10.97 + 1.32 19.65
200 8 219.30 ±0.38 8.18 + 0.99 11.20 12.70 + 1.52 17.50
250 10 273 ±0.38 9.27 + 1.12 9.90 15.06 + 1.80 16.20

Note :
1. For threaded pipes and fittings, the working pressure at 23℃ shall be considered as 50% rating.
2. Pressure rating at uPVC pipes and fittings is tempreture related. Derating factor shall be applied for applications at higher.

Working Pressure for Fittings (Solvent Weld) at 23℃
Scheduled 40 Scheduled 80
Nominal Bore Working Pressure
(mm) (inch) Kg/cm2 Kg/cm2
15 1/2 25.30 35.85
20 3/4 20.25 29.10
25 1 18.95 26.55
32 1 1/4 15.60 21.95
40 1 1/2 13.95 19.80
Working Pressure for Fittings (Solvent Weld) at 23℃
Scheduled 40 Scheduled 80
Nominal Bore Working Pressure
(mm) (inch) Kg/cm2 Kg/cm2
50 2 11.75 16.85
65 2 1/2 – 17.70
80 3 – 15.60
100 4 – 13.50
150 6 7.50 –

Note: Working pressure for metal insert fittings is 15Kg/cm2

FITTINGS RANGE

COUPLER 6KG

pipes-image

Ball Valve

pipes-image

ELBOW

ELBOW-15-150-mm-(1-2-to-6_)

ELBOW 45°

ELBOW-45°-15-50-mm-(1-2-to-2_)

EQUAL TEE

EQUAL-TEE-15-150-mm-(1-2-to-6_)

REDUCING TEE

REDUCING-TEE-20-X-15mm-to-80-X-65mm-(3-4”x-1-2”-to-3”-x-2-1-2”)

FOUR WAY TEE

FOUR-WAY-TEE-15mm-(1-2”)

END CAP

END-CAP-150mm-(6”)

MALE THREADED ADAPTOR

MALE-THREADED-ADAPTOR-15-to-100mm-(1-2”-to-4”)

FEMALE THREADED ADAPTOR

FEMALE-THREADED-ADAPTOR-15-to-100mm-(1-2”-to-4”)

REDUCER

REDUCER-25-X-15mm-to-40-X-32mm-(1”x-1-2”-to-1-1-2”-x-1-1-4”)

REDUCING BUSH

REDUCING-BUSH-20-X-15mm-to-50-X-40mm-(3-4”-x-1-2”-to-2”-x-1-1-2”)

CROSS OVER

CROSS-OVER-15-to-25mm-(1-2”-to-1”)

UNION

UNION-15-to-50mm-(1-2”-to-2”)

TANK CONNECTOR

TANK-CONNECTOR-20-&-25mm-(3-4”-&-1”)

FLANGE WITH SOCKET

FLANGE-WITH-SOCKET-25-to-100mm-(1-2”-to-4”)

BLIND FLANGE

BLIND-FLANGE-65-&-100mm-(2-1-2”-&-4”)

FABRICATED BEND

FABRICATED-BEND-15-to-50mm-(1-2”-to-2”)

FEMALE THREADED ADAPTOR (BRASS INSERT)

FEMALE-THREADED-ADAPTOR-(BRASS-INSERT)-15-to-50mm-(1-2”-to-2”)

MALE THREADED ADAPTOR (BRASS INSERT)

MALE-THREADED-ADAPTOR-(BRASS-INSERT)-15-to-65mm-(1-2”-to-2-1-2”)

FEMALE THREADED ELBOW (BRASS INSERT)

FEMALE-THREADED-ELBOW-(BRASS-INSERT)-15mm-to-25-X-15mm-(1-2”-to-1”x-1-2”)

FEMALE THREADED TEE (BRASS INSERT)

FEMALE-THREADED-TEE-(BRASS-INSERT)-20-X-15mm-to-25-X-15mm-(3-4”x-1-2”-to-1”x-1-2”)

BALL VALVE

BALL-VALVE-15-to-50mm-(1-2”-&-2”)
No details yet!

Product Details

Pipe Dimensions

PIPE DIMENSIONS

Pressure for pipes (Solvent Weld) at 23℃
Scheduled 40 Scheduled 80
Nominal Bore Outside Diameter Wall thickness Working Pressure Wall thickness Working Pressure
(mm) (inch) (mm) (mm) Kg/cm2 (mm) Kg/cm2
15 1/2 21.34 ±0.10 2.77 + 0.51 42.20 3.73 + 0.51 59.75
20 3/4 26.67 ±0.10 2.87 + 0.51 33.75 3.91 + 0.51 48.50
25 1 33.40 ±0.13 3.38 + 0.51 31.60 4.55 + 0.53 44.25
32 1 1/4 42.16 ±0.13 3.56 + 0.51 26.00 4.85 + 0.58 36.60
40 1 1/2 48.26 ±0.15 3.68 + 0.51 23.25 5.08 + 0.61 33.00
50 2 60.32 ±0.15 3.91 + 0.51 19.65 5.54 + 0.66 28.10
65 2 1/2 73.02 ±0.18 5.16 + 0.61 21.10 7.01 + 0.84 29.55
80 3 88.90 ±0.20 5.49 + 0.66 18.25 7.62 + 0.91 26.00
100 4 114.30 ±0.23 6.02 + 0.71 15.50 8.56 + 1.02 22.50
150 6 168.28 ±0.28 7.11 + 0.86 12.60 10.97 + 1.32 19.65
200 8 219.30 ±0.38 8.18 + 0.99 11.20 12.70 + 1.52 17.50
250 10 273 ±0.38 9.27 + 1.12 9.90 15.06 + 1.80 16.20

Note :
1. For threaded pipes and fittings, the working pressure at 23℃ shall be considered as 50% rating.
2. Pressure rating at uPVC pipes and fittings is tempreture related. Derating factor shall be applied for applications at higher.

Working Pressure for Fittings (Solvent Weld) at 23℃
Scheduled 40 Scheduled 80
Nominal Bore Working Pressure
(mm) (inch) Kg/cm2 Kg/cm2
15 1/2 25.30 35.85
20 3/4 20.25 29.10
25 1 18.95 26.55
32 1 1/4 15.60 21.95
40 1 1/2 13.95 19.80
Working Pressure for Fittings (Solvent Weld) at 23℃
Scheduled 40 Scheduled 80
Nominal Bore Working Pressure
(mm) (inch) Kg/cm2 Kg/cm2
50 2 11.75 16.85
65 2 1/2 – 17.70
80 3 – 15.60
100 4 – 13.50
150 6 7.50 –

Note: Working pressure for metal insert fittings is 15Kg/cm2

FITTINGS RANGE

COUPLER 6KG

pipes-image

Ball Valve

pipes-image

ELBOW

ELBOW-15-150-mm-(1-2-to-6_)

ELBOW 45°

ELBOW-45°-15-50-mm-(1-2-to-2_)

EQUAL TEE

EQUAL-TEE-15-150-mm-(1-2-to-6_)

REDUCING TEE

REDUCING-TEE-20-X-15mm-to-80-X-65mm-(3-4”x-1-2”-to-3”-x-2-1-2”)

FOUR WAY TEE

FOUR-WAY-TEE-15mm-(1-2”)

END CAP

END-CAP-150mm-(6”)

MALE THREADED ADAPTOR

MALE-THREADED-ADAPTOR-15-to-100mm-(1-2”-to-4”)

FEMALE THREADED ADAPTOR

FEMALE-THREADED-ADAPTOR-15-to-100mm-(1-2”-to-4”)

REDUCER

REDUCER-25-X-15mm-to-40-X-32mm-(1”x-1-2”-to-1-1-2”-x-1-1-4”)

REDUCING BUSH

REDUCING-BUSH-20-X-15mm-to-50-X-40mm-(3-4”-x-1-2”-to-2”-x-1-1-2”)

CROSS OVER

CROSS-OVER-15-to-25mm-(1-2”-to-1”)

UNION

UNION-15-to-50mm-(1-2”-to-2”)

TANK CONNECTOR

TANK-CONNECTOR-20-&-25mm-(3-4”-&-1”)

FLANGE WITH SOCKET

FLANGE-WITH-SOCKET-25-to-100mm-(1-2”-to-4”)

BLIND FLANGE

BLIND-FLANGE-65-&-100mm-(2-1-2”-&-4”)

FABRICATED BEND

FABRICATED-BEND-15-to-50mm-(1-2”-to-2”)

FEMALE THREADED ADAPTOR (BRASS INSERT)

FEMALE-THREADED-ADAPTOR-(BRASS-INSERT)-15-to-50mm-(1-2”-to-2”)

MALE THREADED ADAPTOR (BRASS INSERT)

MALE-THREADED-ADAPTOR-(BRASS-INSERT)-15-to-65mm-(1-2”-to-2-1-2”)

FEMALE THREADED ELBOW (BRASS INSERT)

FEMALE-THREADED-ELBOW-(BRASS-INSERT)-15mm-to-25-X-15mm-(1-2”-to-1”x-1-2”)

FEMALE THREADED TEE (BRASS INSERT)

FEMALE-THREADED-TEE-(BRASS-INSERT)-20-X-15mm-to-25-X-15mm-(3-4”x-1-2”-to-1”x-1-2”)

BALL VALVE

BALL-VALVE-15-to-50mm-(1-2”-&-2”)
No details yet!

Do's & Don'ts

Design Stage

Do's thumbs up

  • Consider provision for expansion and contraction of piping installation

Don'ts thumbs down

  • Consider pressure de-rating factor for use of upvc pipe line at higher temperature for a maximum of up to 45℃.
Handling, Transpotation & Storage

Do's thumbs up

  • UPVC Pipes and fittings shall be stored in covered area.
  • Pipes shall be stored on levelled flat forund.
  • The shacking height of a upvc pipe stack shall not be more than 50 meters

Don'ts thumbs down

  • Do not drag or drop/throw pipes while loading/unloading & shifting.
  • Do not overhang the pipes out of vehicle body while transporting.
  • Don not stack the pipes for more than 1.5 meters of height.
Jointing & Installation

Do's thumbs up

  • In case of threads to be done in pipes, parallel threads are recommended.
  • Use only uPVC Solvent cement for jointing. Other types of solvent cements may contain ingredients which are not recommended.
  • Cut the pipe at right angle to its axis.
  • Before making joint, remove burr and clean the pipe surface/threads.
  • For Solvent cement joints rotate the pipe through the quator turn while inserting in the upvc fitting.
  • Clean excess solvent cement which comes out from joint.
  • Cure the solvent joint for 24 hours for atleast 24 hours in dry weather & 48 hours in humid weather.
  • For threaded joint, use teflon tape for thread smiling.
  • Use recommened spacing for clamping the installation.
  • In Case of concealed pipeline, plastoring with 1:4 mortar is recommended

Don'ts thumbs down

  • Do not use Solvent cement whick is gelled/not free flowing.
  • While solvent cementing avoid heat exposure or open flame.
  • Do not hammer the pipeline.
  • Do not over-tighten the treaded joints.
Testing Commissioning

Do's thumbs up

  • Pressure test the installation with water only.
  • Before testing, ensure that all joints are cured fully.
  • Ensure that all waves are air relief mechanism at the end of elevations are opened.
  • During initial filling of pipeline,limit water velocity up to 0.3m/s for releasing the entrapped air.
  • Continue fillig until entrapped air is completely removed from installation

Don'ts thumbs down

  • Do not use air or gas for installation testing.
